Q16: NEW VERSION!

BANNER Q16 5N-1

ACP extends the Q16 family. 12 Detents Version is now available for this Rotary Potentiometer Switch. You can choose from several torque levels: 3, 4, 5 and 6Ncm. Thanks to its high robustness and electrical stabilization, the Q16 is suitable to be introduced into Home Appliances market as Function Selector: Washing Machines, Dishwashers, Clothes Dryers, Electric Ovens, Kitchen Robots, etc… Contact ACP’s Customer Service team or your nearest ACP local distributor for further information and sample request.

CS14 HP: NEWCOMER!!!

CS14 HP - Oven2

CS14 HP Pluggable endless turn potentiometer ACP introduces the CS14 endless turn potentiometer suited to be mated with a RAST 2,5 card edge connector. The three pins of the potentiometer (the collector and the two terminals) are fitted into a 1,55 mm thick plastic housing with a pitch of 2,5mm. The disposition of the three pins is such that a portion of their surface will get in touch with the metal contact beams of the card edge connector when plugged together. In order to ensure a good electrical connection, the contact surface of the pins is tin plated. The configuration of the plastic housing that accommodates the three potentiometer contacts includes a polarizing slot to prevent incorrect connection of the connector. There are two options to select the location of the slot, either between the initial terminal and the collector or between the collector and the final terminal. The plastic housing shape also incorporates two side entries to allow the latching of the mating connector, either by means of two side hooks or by a sliding tab from the top surface, depending on the connector system chosen. All the existing CS14 rotors, models, ohm values, shafts and accessories can be supplied with this pluggable version. Examples are features like extended mechanical life, mechanical detents, high temperature fitting, assembled shaft, etc.  Furthermore, like in every ACP product family, these potentiometer series can be customized to meet specific requirements. Extended temperature versions covering a range from -40°C to +120°C are available for applications where the working temperature interval exceeds the standard limits of -25°C to+70°C. A typical application would be as feedback position sensor of the cooking style selector of kitchen ovens. Contact ACP’s Customer Service team or your nearest ACP local distributor for further information and sample request.

CS14 series grow!

CS14V-Everel

ACP has extended their CS14 range with the inclusion of the V12.5×5 model and a rotor shape and size, called the “Y” rotor. The V12,5×5 model features a new pin layout that consists of a 5mm distance between terminals and 12,5x5mm raster. The “Y” rotor is characterized by a reduced size 3 x 4mm “D” shape. The combination of these two features together allows this endless turn potentiometer to be compatible with existing models in the market. Like all the other members of the CS14 family, this new version can withstand temperature ranges from -25ºC to + 105ºC, (or even 120ºC) when configured with the corresponding materials. Contact ACP’s Customer Service team or your nearest ACP local distributor for further information and sample request.

NEWCOMER: RS9 – Rotary Sensor

RS9 SERIES

ACP expands the range of potentiometer Position sensors with the introduction of the new RS9 series, a 9mm Rotary Sensor that withstands up to 200.000 cycles in a mechanical angle of 240º±10º and for operating temperatures between -25ºC and +85ºC. The product is available on all the existing models of the CA9 series in THT, THR and SMD configurations, in bulk and Tape-n-Reel packaging. The standard value is 10K Ohm ±30%, featuring a 3% independent linearity. Other ohm values and linearity are available under request. Typical application is as angle position sensor in a number of different products like actuators for valves, flaps and automotive rear mirrors; gear shafts, robotics etc. The RS9 is also a cost effective man/machine interface to control or regulate a device or an equipment for more than 10.000 mechanical cycles. All the existing rotors, terminals styles, shafts and thumbwheels already available on our CA9 product family can be configured as RS9 long life sensor. In addition to that, we can offer gear wheels under specific customer requests. ACP is ready to offer bespoke solutions for long life applications based on thick-film technology. We have the elements that allow us to approach a broad variety of mechanical and electrical configurations in order to custom design solutions that will meet your specific needs. Please, call us to discuss your project to engineer a solution together.   Contact ACP’s Customer Service team or your nearest ACP local distributor for further information and sample request.

NEW DISTRIBUTOR – JPR Electronics (UK)

ACP is delighted to welcome JPR Electronics as new distributor. Since 1979 JPR Electronics have been in the business of supplying electronic components and accessories to manufacturers, sub-contractors, designers, distributors, MOD, government departments and educational establishments. This commitment supposes an extension of our brand and custom services in a remarkable market as UK.

CA9/CE9 – THT potentiometers in T&R packaging

Manual assembly of odd form through-hole mount components is a costly process. Customer’s in house automation and commercial equipment solutions exist nowadays in the market for automating this operation with the consequent cost reduction. Different ways to feed these components to this type of machines exist. The popular Tape-n-Reel packaging used in SMD components has become a common one to do so. Configured either or for Wave (THT) or Reflow soldering THR), ACP CA9 and CE9 through-hole mount potentiometers packed in Tape-n-Reel are hence suitable for this automated assembly process. Different pocket versions of the T&R carrier allows picking up the potentiometers either, by means of a gripper or a vacuum nozzle. Readily available in this packaging are the following models: CA9H, Horizontal adjustment (Vertical PCB Mount) Model Terminal tip length: TP25 (2,5mm) Terminal tip length: Standard Terminal style: with SNR snap-in H2,5 x – – HS3,8 – x (3,5 mm) – H5 x – –   CA9V, Vertical adjustment (Horizontal PCB Mount) Model Terminal tip length: Standard (4mm) Terminal tip length: TP25 (2,5mm) Terminal style: Standard with SNR snap-in Thumbwheel WT-9002 NO YES V7,5 x – – x x V10 x x Under request x x VR10 x – – x x   Contact ACP’s Customer Service team or your nearest ACP local distributor for further information and sample request.

CS14 CFF – Reinforced Collector

ACP team is delighted to highlight the CS14 carbon endless sensor with reinforced collector (CFF). This mechanical feature provides it a stronger robustness. Thanks to these side ears, whatever additional force applies over the rotor when you introduce a shaft prevents further damage to the potentiometer´s internal structure. In addition, controllers for Appliances and Thermostats are suitable to add detent option in order to assure a specific output value with a narrow tolerance or to add a click feeling. Feature already available in our catalogue. For more details, surf our web and please, get in touch with your ACP sales channel for technical advice and orders

MEGASAN promotes ACP products range at Circuit Magazine

ACP continues with product range promotion. Our Turkish distributor MEGASAN is promoting ACP brand by means of Circuit Magazine. The article appeals to our history, emphasizing our presence in more than 40 countries as well as our great capacity to provide customized solutions. From our standard products to our most advanced solutions, you can find all of them in this monthly magazine. For more details, surf our web and please, get in touch with our ACP sales channel for technical advice and orders. MEGASAN is an authorized ACP distributor in Turkey and provides service with local stock and through their qualified sales team.

Nueva convocatoria Junta General Ordinaria de Accionistas, 2020

Se vuelve a convocar Junta General Ordinaria de Accionistas que en su día fue desconvocada debido a las circustancias generadas por el Covid-19, esperando que la situación lo permita y cumpliendo la ley establecida. (ver PDF) En Tarazona, a 28 de julio de 2020 El Presidente del Consejo de Administración D. Fernando Mercadal Mairal PDF – Nueva convocatoria de Junta General Ordinaria de Accionistas 2020
